Black Acetal Fittings

The PM Range of metric size fittings is manufactured in black acetal copolymer with
food grade nitrile ‘O’ rings. Being especially produced for foodstuff and potable liquids,
they are equally suitable for air and inert gases and can therefore be used on N /CO 2
2
(installed in accordance with the Brewers and Licensed Retailers Association code of
practice) mixed gas dispense lines and pneumatic applications and vacuum.
Technical Information shown on page 36.

STRAIGHT ADAPTOR BSP Thread EQUAL STRAIGHT CONNECTOR REDUCING ELBOW CONNECTOR

PART NO. TUBE
PART NO. TUBE THREAD OD
OD BSP PART NO. TUBE TUBE
OD

OD
PM010411E 4 x 1/8 PM0404E 4
PM010412E 4 x 1/4 PM0405E 5 PM210604E 6 - 4
PM010511E 5 x 1/8 PM0406E 6 PM210804E 8 - 4
PM010512E 5 x 1/4 PM0408E 8 PM210806E 8 - 6
PM010611E 6 x 1/8 PM0410E 10 PM211004E 10 - 4
PM010612E 6 x 1/4 PM0412E 12 PM211006E 10 - 6
PM010811E 8 x 1/8 PM0415E 15 PM211008E 10 - 8
PM010812E 8 x 1/4 PM0418E 18 PM211208E 12 - 8
PM010813E 8 x 3/8 PM0422E 22 PM211210E 12 - 10
PM011012E 10 x 1/4
PM011013E 10 x 3/8
PM011014E 10 x 1/2
PM011213E 12 x 3/8
PM011214E 12 x 1/2 REDUCING STRAIGHT CONNECTOR
PM011513E** 15 x 3/8
PM011514E 15 x 1/2 STEM ELBOW
PM011516E * 15 x 3/4
PM011814E 18 x 1/2
PM012216E 22 x 3/4
* No thread seal PART NO. TUBE TUBE
** New OD OD
PM200604E 6 - 4
PM200804E 8 - 4 PART NO. TUBE STEM
PM200806E 8 - 6 OD OD
STRAIGHT ADAPTOR BSPT Thread PM201004E 10 - 4
PM201006E 10 - 6 PM220404E 4 - 4
PM201008E 10 - 8 PM220505E 5 - 5
PM201208E 12 - 8 PM220606E 6 - 6
PM201210E 12 - 10 PM220808E 8 - 8
PM221010E 10 - 10
PM221212E 12 - 12
PART NO. TUBE THREAD PM221515E 15 - 15
OD BSPT
PM221818E 18 - 18
PM010401E 4 x 1/8 PM222222E 22 - 22
PM010402E 4 x 1/4 EQUAL ELBOW
PM010501E 5 x 1/8
PM010502E 5 x 1/4
PM010601E 6 x 1/8
PM010602E 6 x 1/4
PM010801E 8 x 1/8 RIGID ELBOW
PM010802E 8 x 1/4
PM010803E 8 x 3/8 PART NO. TUBE
PM011002E 10 x 1/4 OD
PM011003E 10 x 3/8 PM0304E 4
PM011004E 10 x 1/2 PM0305E 5
PM011203E 12 x 3/8 PM0306E 6
PM011204E 12 x 1/2 PM0308E 8
PM0310E 10 PART NO. TUBE THREAD
OD

NPTF
PM0312E 12
PART NO. TUBE THREAD
OD NPTF PM0315E 15 PM480621E 6 x 1/8
PM0318E 18 PM480622E 6 x 1/4
PM010622E 6 x 1/4 PM0322E 22 PM480623E 6 x 3/8
