Page 33 - PRESS-FIT SYSTEMS FOR DIVERSE APPLICATIONS
P. 33

S68FFCP/6359
               Flat faced union adaptor
               Press x female union end




                  Size      l1    d1    D1     z1   slw1   sks1   I2    z2   slw2   sks2  DN1      DN2     Code
              15mm x G3/4"  30    15     23    10    30    34     11    3     30    34   DN12   3/4" (DN20)  38742
